Understanding Harmonic Studies in Offshore Wind Power Systems

Calendar icon. D

May 16, 2025 | Blog

Offshore wind turbines and a maintenance platform in the ocean, yellow support legs.

Introduction

As the demand for renewable energy grows, large-scale offshore wind projects are rapidly becoming a critical part of the power generation mix. However, integrating high-capacity wind energy into existing grids introduces several technical challenges—one of which is harmonic distortion. A recent harmonic study conducted for a high-capacity offshore wind farm provides a comprehensive case study on how harmonic emissions impact grid quality and what measures are necessary to ensure compliance with IEEE 519-2022 and IEC 61000-3-6.

In this context, harmonic studies for offshore wind projects play a critical role in maintaining offshore wind grid compliance. Offshore wind harmonic analysis helps utilities and developers quantify harmonic distortion at the point of interconnection and demonstrate compliance with applicable power quality standards.


What Is a Harmonic Study and Why Is It Important?

Harmonics are voltage or current waveforms that deviate from the ideal sinusoidal shape due to non-linear loads, such as power electronics in wind turbines. A harmonic study evaluates the extent to which these distortions can impact system performance, particularly at the Point of Interconnection (POI).

From an interconnection perspective, harmonic analysis at the point of interconnection is essential to ensure offshore wind projects do not adversely impact transmission system voltage quality. Offshore wind interconnection studies routinely include harmonic assessments to validate compliance before energization.


Key risks of harmonic distortion:

Offshore wind power quality is particularly sensitive due to long submarine cable lengths, converter-based generation, and high system impedance. Comprehensive power quality studies for offshore wind projects help identify resonance risks and guide effective mitigation strategies.


  • Equipment overheating
  • False tripping of protection systems
  • Resonance phenomena
  • Regulatory non-compliance



To mitigate these risks, utilities and project developers must assess harmonic emissions under various scenarios and verify compliance with grid codes such as IEEE 519-2022 and IEC 61000-3-6.


Study Overview

A recent harmonic study evaluated the potential voltage distortions of an offshore wind project consisting of 74 wind turbines (18 MW each), arranged across three wind parks. The system involved multiple voltage levels—3.3 kV, 66 kV, 275 kV, and 345 kV—and included a 106 km submarine and land cable transmission path.


Tools and Methodology:

  • Simulations conducted in PSCAD
  • Modeled transformers, cables, and shunt devices
  • Harmonic current injection at 66 kV turbine terminals
  • Background harmonic injection at the 345 kV POI

Combined scenario for worst-case analysis

PSCAD harmonic modeling enables time-domain evaluation of converter-driven distortion and resonance behavior that cannot be captured using simplified frequency-domain tools. This approach is widely adopted for offshore wind harmonic studies involving long export cables and high-capacity turbines.


Key Methodology

The study included:

System Intact (N-0) and Contingency (N-1) scenarios and three harmonic conditions:

  1. Turbine terminal injection
  2. POI background injection
  3. Combined injection

All were assessed against the IEEE 519-2022 and IEC 61000-3-6 distortion limits.


Major Findings

1. Individual Harmonic Order Violations

Distortion from the 9th, 13th, 14th, 15th, 19th, 20th, and 21st harmonics exceeded IEEE/IEC limits—especially without filtering.

2. Total Harmonic Distortion (THD)

Combined injection scenarios showed THD up to 2.4% at 345 kV, exceeding the IEEE 1.5% limit.

3. Load Sensitivity

Distortion remained high regardless of load conditions (peak vs. light), indicating the need for filters independent of demand.

4. Conservative Assumptions

Worst-case background harmonics assumed per IEEE 519 revealed the importance of mitigation even under conservative modeling.


Recommendations

  • Conduct On-Site Harmonic Measurements
    Real-time harmonic monitoring at the POI is essential for accurate risk profiling.
  • Install Harmonic Filters
    Passive or tuned filters should be designed and implemented to maintain compliance.
  • Verify System Models
    Align turbine and transformer MVA ratings to enhance study accuracy.
  • Add Power Quality (PQ) Meters
    Future studies should
    correlate PSCAD simulations with PQ meter data for validation.

Industry Standards Compliance

The study followed these international standards:

  • IEEE 519-2022 – Limits on individual harmonics and THD by voltage class
  • IEC 61000-3-6 – Limits for emission levels in public power systems

ANSI C84.1 – Defines standard voltage classifications

Compliance with harmonic limits defined by IEEE and IEC is a core requirement for offshore wind POI compliance, particularly for projects connecting to high-voltage transmission systems.


Why Harmonic Studies Matter for Offshore Wind Projects

Offshore wind farms increasingly rely on power electronics, increasing the risk of harmonic distortion at the POI. A well-executed harmonic study ensures:

Investor confidence in system reliability

For offshore wind developers, early harmonic analysis reduces interconnection risk, avoids late-stage redesign, and improves confidence among utilities, regulators, and investors evaluating long-term grid performance.


Ensure Your Offshore Wind Project Meets Grid Compliance

Keentel Engineering performs PSCAD-based harmonic studies, power quality analysis, and IEEE/IEC compliance verification for offshore wind developers.

📩 Contact us today to ensure your wind energy project is grid-ready and compliant.
